One Way Vision

Description

Description:

Film: 140micron; black & white PVC film

Adhesive: transparent adhesive

Liner: 140gsm white PEK paper with one side PE & Silicon coating

Width: 0.98/1.06/ 1.27/1.37/1.52m

Features:

1. One side visual, sun-shade and privacy protection; Hole size 1.60mm, perforation 40%;

2. Stable ink absorption and excellent dimensional stability.

Applications:

1. Applicable to glass surface, also applicable to transparent acrylic, PVC, PET transparent panels;

2. Suitable for various solvent ink and Eco-solvent ink.

Technical Data:

Testing condition: Indoor temperature 23±2°C; Relative humidity 50±5%; Use aluminum, glass, steel plate as the base material for testing.

Test Items	Units	Test method	Average value
Thickness PVC Weight-Liner Weight -finished product 24h, 180°peel Dimensional stability MD Dimensional stability CD Tensile strength MD Tensile strength CD Construction Temperature Applicable Temperature	Micron g/m² g/m² N/25mm mm mm N/25 mm N/25 mm ℃ ℃	GB/T6672-2001 GB4669-1995 GB4669-1995 FTM 1 FTM 14 FTM 14 GB/T1040.1-2006 GB/T1040.1-2006	140±10 140±10 270±20 ≥4 ≤1.5 ≤1.0 ≥25 ≥20 20±10 -20 ~ +70



All technical data is subject to change without prior notice.

Code	PVC Film（Micron）	Release Paper（g）	Width(m)	Length	Ink
TR0812G	120	120	1.07/1.27/1.37/1.52	50/100/250
TR0814G	120	135	1.07/1.27/1.37/1.52	50/100/250
TR0814G	140	140	1.07/1.27/1.37/1.52	50/100/250
